Bison Traffic Advisor is a complete solution for traffic advising and warning.
Unique visor design and tall light emitting surface allows for superb clarity even under sunlight.
- A complete solution for traffic advising and warning with panel controller, cable and mounting
- Focused, seamless and high intensity warning visibility
- Unique visor design and tall light emitting surface allow superb clarity even under sunlight.
- Plug-n-play cable design for quick and simple installation
- Programmable for cruise mode and/or end-flasher mode
- LED indicators on controller for instant pattern display in car
- Solid Aluminium extrusion for heat dissipation
- Non-volatile memory recalls last flash pattern used at power up
- EMC and reverse polarity protection
Technical specifications for:
(depending on flash pattern)
|1.15A @12VDC & 24VDC|
|Max. Current||2.3A @12VDC & 24VDC|
|Avg. current (depending on flash pattern)||13.8W @12VDC
|Maximum power||27.6W @12VDC
|Wires||RED +VDC @20AWG
BLACK -GND @20AWG
BLUE IGN (ignition) @20AWG
PURPLE AUX (auxiliary) @20AWG
|Operating temperature||-40°C to +60°C|
|Storage temperature||-40°C to +75°C|
|Certifications*||ECE R10, SAE J595 Class 1, CA13|
*Approvals may vary depending on actual lighthead configuration.
|No of LED elements||32 LED (4x per lighthead)|
|LED color||Blue, red, amber|
Other traffic advisors in our offer can be browsed here.
*The product may differ from image.
