Xtreme Thin XT6 Lighthead uses Xtreme optics for wide light output and classical appearance. Steady-burn pattern for scene / flood light.
Surface or pedestal Mount.
Features:
- 10mm super low-profile thickness
- new generation Xtreme optic for wide angle visual and classic aesthetics
- Long life LEDs rated to 100,000 hours of operation
- Non-volatile memory recalls last flash pattern used at power up
- Multi-unit sync
- Aluminium base for heat dissipation
- Weatherproof and vibration resistant design for external or internal use.
- For external or internal use
- Reverse polarity protection
Technical specifications for Xtreme Thin XT6 Lighthead:
| Voltage | 12-24VDC |
| Avg. Current
(depending on flash pattern) |
0.44A @12VDC
0.22A @24VDC |
| Max. Current | 0.88A @12VDC
0.44A @24VDC |
| Avg. current (depending on flash pattern) | 5.3W |
| Maximum power | 10.6W |
| Wires | RED -Vcc @20AWG
BLACK -GND @20AWG YELLOW -functons and sync @20AWG |
| Wire length | 25mm |
| Fuse | 2A |
| IP rating | IPX8 |
| No of flash petterns | 16 |
| Certifications* | ECE R65 (XA1, XB1), ECE R10, SAE J595 Class 1, CA13 (R, B) |
*Approvals may vary depending on actual lighthead configuration.
LED specifications:
| No of LED elements | 6x High Power LEDs |
| LED color | Blue, red, amber, white |
| Lens colour | Clear |
Dimensions:
Mounting options:
The full range of available lightheads can be browsed here.
*The product may differ from image.
