Fusion FSM Dual Stack Surface Mount Lighthead brings professional quality at affordable prices. No other lighthead series can compare to the Fusion lighthead series.
The Dual Stack Lighthead comes in blue, red, amber, green and white. It can also be combined in red/white, blue/white, amber/white, amber/red, amber/blue, red/blue.
Features:
- Choice between wide-angled or focused CREE LED optics
- Uv resistant and water resistant polycarbonate lens
- 3 programmable modes (‘flood’, ‘cruise’, ‘STT’)
- 7 mounting options
- 40 flash patterns
- 12x LED single colour elements
Technical specifications for Fusion FSM Dual Stack Lighthead:
| Operating voltage | 10 –18V DC |
| Current Draw | 1.5A |
| Cable length | 254mm |
| LED elements (Dual Stack) | 12x 4W Cree LEDs |
| IP rating | IP 66 |
| Certifications* | ECE R65 Class 1, SAE J1113-11, SAE J595, NFPA, KKK, CA Title 13 |
*Approvals may vary depending on actual lighthead configuration.
Connection and mount:
The full range of Lightheads in our offer can be browsed here.
*The product may differ from image.
