Micro Bar EXD with Low Power operation is a dual colour lightbar in blue and amber.
It comes equipped with an Ambient Light Sensor for ambient light detection. It automatically activates or deactivates Low Power mode in darker conditions.
It can be installed using magnetic or permanent mounts and synchronised with other units.
Features:
- ECE R65 Class 2 for Blue colour
- Ambient Light Sensor automatically activates or deactivates the Low Power operation mode in lower light conditions.
- Non-volatile memory recalls last flash pattern used at power up
- Water and vibration resistant for internal or external use
- Reverse polarity protection
- Multi unit synchronisation in simultaneous or alternating flash
Technical specifications for Micro Bar EXD minibar with Low Power operation:
| Voltage | 12–24 VDC |
| Average current | 3A @12VDC
1.5A @24 VDC (depending on flash pattern) |
| Max power | 6A @12VDC
3A @24VDC |
| Avg. Power | 36W |
| Max. current | 72W |
| Magnet Mount | Putem auto-upaljača s dva prekidača |
| Permanent Mount | RED -Vcc @16AWG
BLACK -GND @16AWG WHITE -memorija, rad u smanjenoj potrošnji 20AWG YELLOW -uzorci bljeskanja, boja, sinkronizacija 20AWG |
| Cable length | Magnetic Mount – 300cm
Permanent Mount – 30cm |
| Fuse Rating | 9A |
| Certifications* | ECE R65 (TA1, TB2), ECE R10, SAE J845 Class 1 |
| No of LED elements | 72x High Power LED |
| LED colours | Blue, amber |
| Lens colour | Clear |
| Flash pattern | 1 |
| Synchronization | 15 |
*Approvals may vary depending on actual lightbar configuration.
Dimensions:
Mounting options:
The full range of Lightbars in our offer can be browsed here.
*The product may differ from image.
