Shop / Emergency lighting / Blue Line / Mini Lightbars
  • Micro bar EXD
  • Micro bar EXD
Filter
Micro bar EXD
Micro Bar EXD mini krovna konzola
Micro bar EXD
Micro Bar EXD mini krovna konzola

Micro Bar EXD Minibar

Micro Bar EXD dual colour minibar.

Can be installed permanently or on a magnetic mount.

Add to Quote loading
Categories: Blue Line, Emergency lighting, Mini Lightbars Tag: Juluen
Kategorije proizvoda
  • Communication Equipment
    • Accessories
    • Antennas
    • INTERCOM
    • Radios
  • Control Units
    • Controllers
    • Handsets
  • Emergency lighting
    • Amber Line
      • Beacons
      • Lightbars
      • Lightheads
      • Mini Lightbars
      • Road lighting displays
      • Traffic advisors
    • Blue Line
      • Beacons
      • Lightbars
      • Lightheads
      • Mini Lightbars
      • Stealth Plate
      • Traffic Advisors
  • Equipment for people with disabilities
    • Lifts and ramps
    • Safety Restraints
    • Seating
    • Smartfloor
    • Steps
    • Swivel seats
  • Matins custom
  • Optional Equipment
    • Heaters
    • High pressure kits
    • Lifting loads
  • Other equipment
    • Back-up Beeper
    • Parking sensors
    • Video systems
  • Power supply
    • Battery chargers
    • Charging systems
    • Desktop chargers
    • Inverters
    • Low Voltage Protector
    • Sockets/chargers
    • Voltage converters
  • Sirens and Speakers
    • Sirens
    • Speakers
  • Work Lighting
    • Flashlights
    • Interior lighting
    • Scene lighting
    • Spotlights
    • Telescopic masts
  • Description

Micro Bar EXD minibar is an extremely compact dual colour lightbar.

It can be installed using magnetic or permanent mounts and synchronised with other units.



Features:

  • Quad memory capability
  • Non-volatile memory recalls last flash pattern used at power up
  • Water and vibration resistant for internal or external use
  • Reverse polarity protection
  • Multi unit synchronisation in simultaneous or alternating flash



Technical specifications for Micro Bar EXD Minibar:

Voltage 12–24 VDC
Average current 3A @12VDC

1.5A @24 VDC (depending on flash pattern)

Max power 6A @12VDC

3A @24VDC

Avg. Power 36W
Max. current 72W
Magnet Mount Putem auto-upaljača s dva prekidača
Permanent Mount RED -Vcc @16AWG

BLACK -GND @16AWG

WHITE -memorija, rad u smanjenoj potrošnji 20AWG

YELLOW -uzorci bljeskanja, boja, sinkronizacija 20AWG

Cable length Magnetic Mount – 300cm

Permanent Mount – 30cm

Fuse Rating 9A
Certifications* ECE R65 (TA1, TB2), ECE R10, SAE J845 Class 1
No of LED elements 72x High Power LED
LED colours Blue, red, amber, green, white
Lens colour Clear
Flash pattern 26
Synchronization 15

*Approvals may vary depending on actual lightbar configuration.



Dimensions:

Micro Bar EX

Mounting options:

nosač mini krovna konzola
nosač mini krovna konzola
nosač mini krovna konzola

The full range of Lightbars in our offer can be browsed here.

*The product may differ from image.
