Aegis LED Double Layer Lightbar is adaptable and durable with only 83mm of height that allows excellent visibility. Thanks to the double layer design, the switch between light colours is instantaneous and immediately noticeable. Built-in Traffic Director makes the lightbar easy to use in many situations.
- Durable casing and outline with a modern design and elegant look
- Powerful optics: original Aegis corner optics that meets ECE R65 Class2 and SAE J845 Class 1 standards
- Double Layer Lightbar: individually controlled uper and lower layer with dual colour lightheads
- 83mm thickness for broad visibility and powerful output
- Coloured Top: any colour top cover to show designation
- Optional special lightheads takedown or alley lights
- Tough outline with modern design and a solid, sturdy look
Technical specifications for Aegis Double Layer LED Lightbar:
|Operating voltage||12 or 24 VDC|
|Cables||ONE CABLE MODEL
– 1x +Vcc power wire @10AWG
– 1x -GND power wire @10AWG
– 2x speaker wire @20AWG
– 8x function wire @22AWG
TWO CABLE MODEL
– 2X +Vcc @12AWG
– 2X -GND @12AWG
– 2X speaker wire @20AWG
– 16X function wire @22AWG
|Certifications*||ECE R65 Class2 (TA2/TB2/TR2), ECE R10, SAE J845, CA Title 13,|
|Flash pattern||15 patterns x 5 flash groupings|
|LED colours||Amber, white, green|
*Approvals may vary depending on actual lightbar configuration.
|Lightheads||Number of LEDs|
|Corner Lighthead Optics||9X LED D-Fuser Single Colour
9+9 LED D-Fuser Dual Colour
|Middle LIghthead Optics||6+6 LED Double Layer|
|Optional Lightheads||3X LED Alley Lights
6X LED Take-Down / Work Lamp
Other lightbars in our amber programme can be browsed here.
*The product may differ from image.
