S006 Programmable Siren and Control System

200W siren supports the use of 2 speakers (2x 100W).

Record instant replayable messages up to 20 seconds.

‘Mix tone’ function allows each speaker for a Multi-Speaker Effect.

S006 Programmable Siren and Control System is easily customised to user needs. Fully programmable and customizable configuration with PC software.

The 200W siren supports the use of 2 speakers (2x 100W).

Features:

Fully programmable and customizable configuration with PC software
Button Input style: maintained, momentary, timer etc.
Button interlink, interlock and output port
Tone selection: primary, override, mixer, hands-free tone
Separate backlight control and covert mode (backlight disabled)
Selectable tone including Wail, Yelp, Phaser (Piercer), Hi-Lo, Mechanical, European Tone and etc.
Heavy-duty power and output connectors with easily accessible fuses
Radio Re-Broadcasting (RRB) for audio replay
“Record-n-Play” function: record instant replayable messages up to 20 seconds
‘Mix tone’ function allows each speaker for a Multi-Speaker Effect
Programmable for auto low voltage protection

Voltage	12-24VDC
Standby current	≈6 mA (w/o IGN wire) /< 0.35A (w IGN wire)
AUX port
Max. Current	20A @12VDC / 10A @24VDC (w/o light control outputs) 100A @12VDC / 50A @24VDC (w/ light control outputs)
Siren Output Power	200W (2x 100W speaker), 11 Ω
Wires	Input voltage High Current Output x3 Logic input x4 Radio Audio Input Controller Port Speaker Output x2 IGN Mid/Low Current Output x9 Voltage-variable Analogue Input x1 Microphone TRS (optional) PC Link USB Port
Wire length
Fuse	Blade fuse: 30A x1, 15A x3, 10A x3, 2A x2 Resettable fuse: 0.25A x4
Operating temperature	-30°C to +65°C
Certifications*	ECE R10, SAE J1849 EVS1
